Connecting 11.1-channel speakers
This system, which is based on a 5.1-channel system, plays back up to 11.1-channels at the same time.
You can connect speakers for 11-channels for MAIN ZONE by using an external power amplifier.
o
Example connection when using two sets of ceiling speakers
.
C
FL FR
SBL
SBR
SW
SL SR
TRL TRR
TFL TFR
0
Set “Height” - “Height Sp” to “4ch” in the menu when connecting in this
configuration. (v
p. 219)
.
HEIGHT 1
z
TFR TFLSBR SBL
FR FL C SR SL
SW
TRR TRL
HEIGHT 2
z
Power amplifier
z
You can change the combination of the HEIGHT1 and HEIGHT2 channels in the
settings. (v
p. 63)
Contents
Connections Playback Settings Tips Appendix
59
Front panel Display Rear panel Remote Index

Denon AVR-X4400H Specifications

General

Display	-
ECO mode	Yes
HDCP version	2.2
Apple docking	No
Product color	Black
Audio decoders	DTS:X, Dolby Atmos
Audio formats supported	ALAC, DSD, FLAC, WAV
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Supported radio bands	AM, FM
Supported graphics resolutions	4096 x 2160
RS-232 ports	1
Connectivity technology	Wireless
HDMI in	8
Composite video in	4
Component video (YPbPr/YCbCr) in	2
Receiver type	Surround
Frequency range	10 - 100000 Hz
Pre-out channels	11.2
Input sensitivity	200 mV
Audio output channels	9.2 channels
Signal-to-Noise Ratio (SNR)	100 dB
Power output per channel (1KHz@6 Ohm)	200 W
Power output per channel (20-20KHz@8 Ohm)	125 W
AC input voltage	230 V
AC input frequency	50 Hz
Power consumption (standby)	0.5 W
Power consumption (typical)	710 W
Number of HDMI outputs	3

Weight and Dimensions

Depth	389 mm
Width	434 mm
Height	167 mm
Weight	13500 g
