Denon AVR-X6800 User Manual

Height speakers Layout
0
Use the following illustration as a guide for the installation location of each height speaker. You do not have to match them exactly.
z
1
z2
z
3
z4
z5
z1 30° - 45°
z4 125° - 150°
z2 30° - 55°
z3 65° - 100°
z5 135° - 150°
Point slightly
downwards
GViewed from the sideH
Top front speaker Top rear speaker
Front speaker
Surround
speaker
Surround
back
speaker
Point slightly
downwards
Rear height
speaker
Top middle / Top surround speaker Surround height speaker
Front height /
Center height
speaker
TS
SL
TRL
RHL RHR
FHL
TML
TFL
FL
SR
TRR
FHRCH
TMR
TFR
FR
C
SHRSHL
GViewed from the topH
Contents Connections Playback Settings Tips Appendix
39
Front panel Display Rear panel Remote Index
