Setup
Getting Started:
1. Connect any microphones to the mic inputs or line-level devices to the line inputs.
2. Connect your speakers to the Speaker Out using a properly wired 4-pin Euroblock
connector and speaker wire. The power of each output is less than 120 W (without
distortion). Use only one output at a time.
3. Make sure all Level knobs are set to “MIN”.
4. Connect the included power cable from the power input to a power outlet; power on
DN-333XAB.
5. Adjust the individual channel Level knobs and the Speaker Level knob to get a strong
signal without distortion or “clipping”.
6. Adjust the Speaker Treble and Speaker Bass knobs to further control the frequencies of
the sound.
Using a Euroblock Connector (see the side graphic):
1. Twist the speaker wire to form a tight strand and
insert this into the appropriate port, (following the
indication located above the pins on DN-333XAB)
pushing the wire until it is secured inside.
2. Attach the Euroblock connector to the input terminal
on DN-333XAB.
3. To disconnect a wire, use a small screwdriver to
press in the spring above the insert port while pulling
out the wire.
Items not listed under Introduction > Box Contents are sold separately.
Power
Speaker
Bluetooth
Device
Microphone
MIC 1
PRIORITY
