27
DN-HS5500
133 J5 CVDL I - - - - Core supply (+1.2V)
134 J6 D_GND - - - - - GND
135 J7 D_GND - - - - - GND
136 J8 D_GND - - - - - GND
137 J9 D_GND - - - - - GND
138J10 D_GND -----GND
139J11 D_GND -----GND
140 J12 CVDL I - Core supply (+1.2V)
141 J13 SHDB15 I/O - - - - CPU bus data 15
142 J14 DVDH I - - - - I/O supply (+3.3V)
143 J15 AEMA1 O - - - - External memory bus address 1
144 J16 AEMA0 O - - - - External memory bus address 0
145 K1 D_GND - - - - - GND
146 K2 PLLHV I - - - - PLL supply (3.3V)
147 K3 TMS_A I - - - - Test mode select signal (JTAG)
148 K4 /TRST_A I - - - - Test reset signal (JTAG)
149 K5 CVDL I - - - - Core supply (+1.2V)
150 K6 D_GND - - - - - GND
151 K7 D_GND - - - - - GND
152 K8 D_GND - - - - - GND
153 K9 D_GND - - - - - GND
154K10 D_GND -----GND
155K11 D_GND -----GND
156 K12 CVDL I - - - - Core supply (+1.2V)
157 K13 SHDB0 I/O - - - - CPU bus data 0
158 K14 SHDB1 I/O - - - - CPU bus data 1
159 K15 AEMA2 O - - - - External memory bus address 2
160K16 D_GND -----GND
161 L1 TDI_A I - - - - Test data input (JTAG)
162L2 -----Not used
163L3 -----Not used
164L4 -----Not used
165 L5 D_GND - - - - - GND
166 L6 D_GND - - - - - GND
167 L7 D_GND - - - - - GND
168 L8 D_GND - - - - - GND
169 L9 D_GND - - - - - GND
170 L10 D_GND - - - - - GND
171L11 D_GND -----GND
172 L12 D_GND - - - - - GND
173 L13 SHDB3 I/O - - - - CPU bus data 3
174 L14 SHDB4 I/O - - - - CPU bus data 4
175 L15 AEMA4 O - - - - External memory bus address 4
176 L16 AEMA3 O - - - - External memory bus address 3
177 M1 /EMU0 I/O - - - - Emulation pin 0 (JTAG)
178 M2 TDO_A OZ - - - - Test data out (JTAG)
179M3 -----Not used
180 M4 DVDH I - - - - I/O supply (+3.3V)
181 M5 D_GND - - - - - GND
182 M6 CVDL I - - - - Core supply (+1.2V)
183 M7 CVDL I - - - - Core supply (+1.2V)
184 M8 CVDL I - - - - Core supply (+1.2V)
185 M9 CVDL I - - - - Core supply (+1.2V)
186 M10 CVDL I - - - - Core supply (+1.2V)
187 M11 CVDL I - - - - Core supply (+1.2V)
188M12 D_GND -----GND
189 M13 DVDH I - - - - I/O supply (+3.3V)
190 M14 SHDB2 I/O - - - - CPU bus data 2
191 M15 AEMA6 O - - - - External memory bus address 6
192 M16 AEMA5 O - - - - External memory bus address 5
193 N1 /EMU1 I/O - - - - Emulation pin 1
194N2 -----Not used
195N3 -----Not used
196 N4 AEMD22 I/O - - - - External memory bus data 22
197 N5 DVDH I - - - - I/O supply (+3.3V)
198 N6 AEMD18 I/O - - - - External memory bus data 18
199 N7 AEMD16 I/O - - - - External memory bus data 16
Pin No. Pin Name Symbol I/O DET Ext Ini Res Function
