19
Regular Maintenance
Figure 19. Suspension Lubrication
Top & Bottom, Left & Right
Figure 20. Rear Control Pivot Lubrication
Figure 22. Front Pivot Frame Lubrication
(Front location shown, rear grease fitting located through
clearance hole in brake cover panel.)
Figure 21. Lift Pivot Lubrication
