8
OPERATION - Introduction
Before starting operations in this section:
1) Find a place where there is power supply nearby.
2) As shown below, install the exhaust hose, and adjust the window position well.
3) Insert the power cord into an grounded
AC220~240V/50Hz socket;
4) Press the ON/OFF button to turn on the air-
conditioner.
1. Before using
Notice:
- Operation temperature range:
DB - temperature of dry
themometer
WB - temperature of wet
thermometer
Check up whether the exhaust hose has been mounted properly.
Cautions for cooling and dehumidifying operations:
- When using functions on cooling and dehumidifying, keep an interval of at least 3
minutes between each ON/OFF.
30 c
m
To Next Page
