PARTS
This list contains replaceable parts used in your replace. When ordering parts, follow the
instructions listed under Replacement Parts on page 29 of this manual.



  DESCRIPTION 
1a 122081-04 Back Log • • 1
1b 122081-05 Front Log • • 1
1c 122081-06 Crossover Log • • 1
2 103778-01 ODS Pilot • 1
103779-01 ODS Pilot • 1
3 098249-01 ODS Nut • • 2
4 099387-09 Pilot Tube • 1
100609-01 Pilot Tube • 1
5 104229-02 Burner Outlet Tube • 1
104229-01 Burner Outlet Tube • 1
6 111124 -01 Burner Retainer Spring • • 1
7 099056-19 Burner Orice Injector • 1
099056-26 Burner Orice Injector • 1
8 102772-01 Burner • • 2
9 M11084-38 Screw, #8 x 0.38 • • 2
10 104236-01DD Painted Base Assembly • • 1
11 M12461-26 Screw, #10 x 0.32 • • 4
12 ** Firebox Bottom • • 1
13 103284-03 Wiring Harness • • 1
14 098265-02 Elbow, Male • • 1
15 103782-01 Valve Bracket • • 1
16 103781-02 Gas Control Valve • 1
103781-01 Gas Control Valve • 1
17 098271-03 Ignitor Cable • • 1
18 102445-01 Piezo Ignitor • • 1
19 098304-01 Screw • • 7
20 099998-01 Switch • • 1
21 104241-01 Remote Switch Bracket • • 1
22 103587-01CK Switch Plate • • 1
23 097809-02 Male Connector • • 1
24 101628-03 Flexible Connector (Hose) • • 1
25 M50104-02 Bushing • • 1
26 M11084-26 Screw, #10 x 0.38 • • 4
27 901063-01 93/8" Flare x 1/2" NPT • • 1
28 099918-02 Pilot Regulator (Natural Only) • 1
29 099387-07 Pilot Tube (Valve to Regulator) • 1
PARTS AVAILABLE — NOT SHOWN
097555-01 Caution Decal • • 1
** Not a eld replaceable part.
