113109-01G 33
PARTS
This list contains replaceable parts used in your replace. When ordering parts, follow the
instructions listed under Replacement Parts on page 29 of this manual.
DESCRIPTION
1 101357-03 Top Outer Casing 1
2 ** Outer Casing 1
3 ** Right Front Side 1
4 ** Left Front Side 1
5 098304-01 Phillips Pan Head Screw, #10 9
6 104239-01CK Top Front Louver 1
7 101712-03 Firebox Hood 1
8 ** Firebox Support 2
9 099230-02 Shoulder Screw 4
10 ** Firebox Top 1
11 101346-01 Outer Base 1
12 ** Firebox Wrapper 1
13 101514-01ck Cover 1
14 M11084-26 Hex Screw, #10 45
15 110466-01 Bottom Louvered Door 1
16 101727-03 Screen Assembly 1
PARTS AVAILABLE — NOT SHOWN
101386-02 Louvered Door Hinge 2
101784-01 Magnet Catch 2
** Not a eld replaceable part.
