SPECIFICATIONS Continued

10.5"
17"
0.625"
51"
30.5"
28.5"
21.25"
41.25"
23.5"
24.25"
3.5"
13"
1"
49"
8"
58"
30"
42"
51"
12"
9.5"
8.5"
67"
11"
GAS LINE
KNOCK OUTS
AIR KIT
KNOCK OUT
LEFT SIDE
OUTSIDE AIR
1
1
/
2
" AIR SPACE
BACK AND SIDES
0" TO
BOTTOM
GAS LINE
KNOCKOUTS
12" EACH SIDE
COMBUSTIBLE
WALL BOARD
NO COMBUSTIBLE
MATERIAL ON FACE
MINIMUM 18" TO
PERPENDICULAR
SIDEWALL
HEARTH EXTENSION
66" X 20"
2" CHIMNEY AIRSPACE
CLEARANCE TO
COMBUSTIBLE MATERIAL
ROUND TOP TERMINATION
TERMINATION
SQUARE CHASE-TOP
