PARTS
This list contains replaceable parts used in your rebox. When ordering parts, follow the
instructions listed under Replacement Parts on page 18 of this manual.
KEY

PART NUMBER
DESCRIPTION 
V32AS, V32S
VFB32NC
VFB32ANC
V32, V32A
VFB32C
VFB32AC
1 108441-01 108441-01 Screen 1
2 108700-01 108700-01 Screen Rod 2
3 11418 11418 Push-On Nut 2
4 108414-01 108414-01 Deector Hood 1
5 108423-01 108423-04 Face Top Panel (VFB32NC Smooth Faced) 1
6 108423-01 108423-07 Face Bottom Panel (VFB32NC Smooth Faced) 1
7 ** ** Face Weldment 2
8 106683-01 106683-01 Firebox Support Leg 2
9 108434-01 108434-01 Left Refractory 1
10 108430-01 108430-01 Rear Refractory 1
11 108432-01 108432-01 Right Refractory 1
12 108426-01 108426-01 Bottom Rear Refractory 1
13 108428-01 108428-01 Bottom Front Refractory 1
14 ** ** Firebox Bottom 1
15 ** ** Firebox Surround 1
16 20027 20027 Refractory Retainer 2
17 ** ** Fireplace Top Insulation 1
18 ** ** Firebox Top 1
19 108415-01 108415-01 Starter Pipe Collar 1
20 ** ** Insulation Pan 1
21 108403-03 108403-03 Fireplace Top 1
22 20280 20280 Top Spacer 4
23 ** ** Fireplace Surround 1
24 24353 24353 Handy Box Assembly 2
25 108654-01 108654-01 Gas Conduit Left and Right Assembly 2
26 21171 21171 Gas Knock-Out Cover 4
27 14123 14123 Strain Relief 1
28 106703-02* 106703-02* Air Kit Door Assembly 1
29 108425-01* 108425-01* Air Rod Retainer 1
* Part for “A” models only.
** Not a eld replaceable part.
