www.desatech.com
116662-01G 15
PARTS
MODEL FB32CB
This list contains replaceable parts used in your rebox. When ordering parts, follow the
instructions listed under Replacement Parts on page 18 of this manual.
KEY
NO. PART NO. DESCRIPTION QTY.
1 101872-03 Firebox Top 1
2 101889-01 Firebrick Retainer 3
3 117538-01 Firebrick Kit 1
4 103457-01 Button Plug 1
5 103207-01 Outer Casing 1
6 ** Outer Shell Base 1
7 ** Firebox Wrapper 1
8 103297-01 Assembly Screen 2
9 103217-01CK Hood 1
10 103773-01 Front Assembly 1
11 ** Firebox Bottom 1
12 103809-01 Screen Rod 2
13 M12461-2 Screw, Outlet Mounting 1
14 ** Firebox Support 2
15 101357-03 Outer Casing Top 1
16 M11084-26 Hex Head Screw, #10-16 49
17 103771-01 Strain Relief Fitting 1
18 098304-01 Phillips Pan Head Screw, #10 13
19 099230-01 Hex Head Screw 3
20 099230-02 Shoulder Screw 2
21 GA3555 Duplex Outlet 1
** Not a eld replaceable part.
