PARTS LIST
BURNER ASSEMBLY FOR MODELS
VC42N, VC42P, VVC42N AND VVC42P SERIES
This list contains replaceable parts used in your fireplace. When
ordering parts, follow the instructions listed under Replacement
Parts on page 31 of this manual.
PARTS LIST
Models VC42N, VC42P, VVC42N and VVC42P Series
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 116343-01 Burner Pan Assembly 1
2 111311-02 Base Grate 1
3 116387-02 Firebox Base Bottom 1
4 26808 Valve Bracket 1
5 11107 Screw, #10-32 x 1/4 Zinc 4
6 111310-02 Firebox Bottom 1
7 11102 Screw, #8-32 x 3/8 Zinc 2
8 116344-01 Tubing Assembly 1
9 111288-02 Flex Gas Line 1
10 108084-02 Pilot Assembly (Natural Gas) 1
108084-03 Pilot Assembly (Propane/LP Gas) 1
11 14389 Natural Gas Valve 1
14390 Propane/LP Gas Valve 1
12 11165 Screw, #10 x 5/8 Zinc 23
13 111913-02 Burner Base Gasket 1
14 14500 Brass Fitting 2
15 116345-01 Pilot Bracket 1
16 26827 Switch Bracket 1
17 11226 Flat Washer 7/8" ID x 2" OD 2
18 11214 Bulkhead Fitting with Washer 2
19 14296 Elbow 3/8" 1
20 24874 Burner Orifice #32 (Natural Gas) 1
23098 Burner Orifice #50 (Propane/LP Gas) 1
21 11492 Piezo 1
22 14511 Piezo Bracket 1
