APEX PRO/4
3
FASTEN FRAME AND CONTROL BOX
TO DESK SURFACE
Assemble using the 7/8" length wood screws.
(14 screws total) Secure control unit with 16mm
wood screws (2 screws total)
*Notes - Center base on desk surface leaving 2" on right and left sides.
Pre-drilling holes is required for solid wood tops and optional for HPL tops.
X14
X2
To Next Page
