Desoutter CVI3 Vision Installation And Upgrades

- 34 - 6159924330 - 08/2020
4 2 mounting plates
5 2 screws M4x10
6 Keys
Operator panel
2
3
4
5
1
1 Operator panel
2 Termination plug SubD 9-pt
3 Support rails DIN TSH 35-2
4 Mounting plate accessories
5 2 screws M4x10
I/O expander
1
11
13
14
15
12
10
2
3
4
7
5 8 6 9
1 I/O expander x 1
2 Cable entry system x 1
3 Termination grommet Ø 0 x 7
4 Connector 12-pt - pitch 3.81 x 2
5 Connector 10-pt - pitch 3.81 x 2
6 Connector 2-pt - pitch 3.81 x 2
7 Grommet Ø 4.8 to 5.8 mm x 2
8 Grommet Ø 5.8 to 6.8 mm x 2
9 Grommet Ø 6.8 to 7.8 mm x 2
10 4 screws Hex. M5x15 x 4
11 Plastic bag -
12 Termination plug SubD 9-pt x 1
