Desoutter CVI3 Vision Installation And Upgrades

6159924330 - 08/2020 - 37 -
1
Stacklight (position by default)
IO expander (position by default)
Operator panel (position by default)
1
2 3
1. Remove the front panel to access the encoding wheel
2. Encoding wheel
3. This switch is set to 0. Do not change this setting.
Installing sockets of the socket tray
Internal centering
