Detection Systems DS7400Xi - Page 13

© Radionics Inc. reserves all rights even in the event of industrial property rights. We reserve all rights of disposal such as copying and passing on to third parties.
13
DS7430 Multiplex Expansion
Power Bus
+
+
-
-
Plug into the
Expansion Port of the
control.
200mA of Auxiliary
Power available for
powering devices.
DS7400Xi Panel Wiring & Programming
