42
Data Digit
DS7400Xi Panel Wiring & Programming
Programming Address 0001-0015
1 2 Enter the Data Digit as a:
Select Options 0
1 2 3 4 5 6 7 *2 *3 *4 *5
Invisible Alarm
Silent Alarm
Steady Alarm Output
Pulsing Alarm Output
Alarm on Short
Alarm on Open
Trouble on Open
**
Trouble on Short
*
2 -
*
5 are Hex values. They will display as C-F at keypads.
Next
Slide
** Only when disarmed.
When armed, this becomes Alarm on Open or Short for 24-hr Zones.
Note: Multiplex contacts (DS7450 & DS7452) should not be
programmed for Trouble on Open.
To Next Page
