DS7400Xi Panel Wiring & Programming
Output Programming: Addresses 0146-0148
Select Option DD
ON for 10 sec. After pressing [System Reset] 2
Latch on ANY Zone Alarm [incl Invisible] 0
ON During Entry Pre-Alert 1
ON When System is Armed 3
Ground Start 4
System Status (Ready to Arm) 5
Zone Alarm 6
Zone Alarm delayed by 20 seconds 7
Keypad Sounder Output 8
Access Output (10-second pulse) 9
Panic Duress Output *** *1
PO1 will be ON for 10-sec after Sys Reset pressed.
PO2 will be OFF for 10-sec after Sys Reset pressed.
Options DD
Data Digit
Disabled 0
Burglar Alarm 1
Fire Alarm 2
Burg and Fire Alarm 3
1 2
*** Section 6.4 of
Reference Guide
describes this function
