Output Partition Assignment
DS7400Xi Panel Wiring & Programming
PA0149
PA0150
Data Digit
Data Digit
1
2
Select Option DD
Belongs to Partition 1 0
Belongs to Partition 2 1
Belongs to Partition 3 2
Belongs to Partition 4 3
Belongs to Partition 5 4
Belongs to Partition 6 5
Belongs to Partition 7 6
Belongs to Partition 8 7
Follows all Partitions
8
2 1
Must be 0
0
Output Address Default
Programmable Output 1 0149-DD2 8
Programmable Output 2 0150-DD1 8
Alarm 0149-DD1 8
