PA 0197
A/C Fail Report Delay Programming
The A/C Fail Delay Times are
programmed as Hexadecimal
values.
Example:
00 Send only with next report
1*4 30 Minute Delay
3*2 60 Minute Delay
78 120 Minute Delay
*5*5 Random Delay
(at least 15 but less than 120)
We count 0-9
Hex counts 0-15
To us 30 means 3 tens and 0 ones or
(30 units)
To Hex 30 means 3 sixteens and 0
ones (48 units)
3*2 = 60 because
3x16 equals 48
and *2 equals 12
60
DS7400Xi Panel Wiring & Programming
Data Digit
1 2
0 0
A/C Fail Report Delay
Address 0197
00 through FF
