Octal Relay Module Output Programming
First DS7488 or DS7489
Second DS7488 or DS7489
DS7400Xi Panel Wiring & Programming
Octal
Relay #
Addresses
Octal
Relay #
Addresses
1 1456 9 1464
2 1457 10 1465
3 1458 11 1466
4 1459 12 1467
5 1460 13 1468
6 1461 14 1469
7 1462 15 1470
8 1463 16 1471
First Data Digit defines the specific relay option.
Second Data Digit determines whether relay will associate with Fire,
Burglary, or neither.
To Next Page
