PA1472-1516
Output Function
Programming
DS7400Xi Panel Wiring & Programming
Data Digit
Select Option DD
Follow a single zone *3
Follow 2 zones if either changes *4
1 2
Follow 2 zones if both change *5
Program Address 1
Enter the Data Digit as a:
0 1 2 3 4 5 6 7 8 9 *0 *1 *2
Activate:
Disabled
When zone is shorted
When zone is opened
When panel is Armed
When panel is not Armed
Latch when activated **
** This is only for DS7465 Outputs.
DS7488 Outputs will not latch when activated
To Next Page
