PARTS LIST
HYDRA
ITEM PART # DESCRIPTION
1 B20180
Electric Boiler Assembly
2 B20197
Insulation, left side
3 B02293-20
Insulation
4 B20170
Cabinet panel, left
5 B20168-01
Electrical box, cover
6A B20217
Electrical box
6B B20166
Electrical box right side panel
6C B20117
Electrical box left side panel
7 G11F012
Pressure relief valve, 30 PSI, 3/4" x 3/4"
8 G11Z001
Sediment faucet, 1/2
9 R02L001
Tridicator, 0-75PSI 1/4" NPT
10 B20219
Cabinet
11 B20171
Cabinet panel, right
12 A20013
Thermistor probe
13 L99H001
Water Element, 240V / 5 Kw
14 L99H002
Water Element, 240V / 3 Kw
15 L99H003
Water Element, 240V / 4 Kw
16 A20015
Outdoor sensor, -12°C
17 B20179
Mounting plate
18 B02293-24
Insulation
19 L02G001
Fuse holder, BUSS
20 L01G002
Fuse 2A
21 L01G007
Fuse 15A
22 L01F009
Transformer, 120-24 Volts, 40VA
23 R02F001
Single action aquastat, Honeywell L4008A
24 L01H002
Relay, SPST 24 VDC
25 A20022-01
Electrical wire, black
26 L99F004
Terminal block
27 A20023-01
Electrical wire, red
28 A20009-01
Electrical wire, red
29 L01H024
Contactor 240 VAC
30 A20009-02
Electrical wire, black
31 B20120
Electrical kit
32 B20098
Electronic Board Hydra 3
33 B20119
Electrical kit
