Devolo dLAN 500 WiFi Installation

Erste Schritte:
Stecken Sie den dLAN® 500 duo Adapter in die Steckdose und verbinden Sie ihn mit dem beiliegenden LAN-
Kabel mit Ihrem Router.
First steps:
Plug the dLAN® 500 duo adapter into the power socket and connect it to router with the LAN cable included.
Premiers pas:
Insérez l‘adaptateur dLAN® 500 duo dans la prise de courant et reliez-le à votre routeur au moyen du câble
Ethernet fourni.
Eerste stap:
Steek de dLAN® 500 duo adapter in het stopcontact en sluit deze met bijgevoegde LAN-kabel aan op
uw router.
Primeros pasos:
Enchufe el adaptador dLAN® 500 duo en la toma de corriente eléctrica y conéctelo al router con el cable
LAN incluido.
Primeiros passos:
Introduza o adaptador dLAN® 500 duo na tomada e ligue-o ao seu router através do cabo LAN que vai junto.
Primi passi:
Innestare l‘adattatore dLAN® 500 duo nella presa elettrica e collegarlo al proprio router utilizzando il cavo
LAN presente in dotazione.

Devolo dLAN 500 WiFi Specifications

General

Interface	Ethernet / WLAN
Connectivity technology	Wired & Wireless
Ethernet LAN (RJ-45) ports	1
Safety	CE B
Chipset	-
Internal	No
Product color	White
Modulation	1024-QAM, 256-QAM, 4096-QAM, 64-QAM, BPSK, OFDM, QPSK
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Cabling technology	10/100BaseT(X)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
Security algorithms	128-bit AES, WEP, WPA, WPA2, WPS
Maximum indoor range	300 m
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3u, IEEE 802.3x
Ethernet LAN data rates	10, 100 Mbit/s
Maximum data transfer rate	500 Mbit/s
Supported network protocols	CSMA/CA
AC input voltage	196-250 V
AC input frequency	50 Hz
Power consumption (typical)	4.4 W
Storage temperature (T-T)	-25 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	41 mm
Width	68 mm
Package depth	190 mm
Package width	115 mm
Package height	81 mm
Package weight	260 g
