DeWalt DCCS674 User Manual

13
ENGLISH
Installing and Removing the Battery Pack
(Fig.L)

WARNING: Ensure the tool/appliance is in the off
position before inserting the batterypack.

DANGER: Never use the chain saw with only one
hand. It is more difficult to control reactive forces.
Proper hand position requires the left hand on the front
handle
2
, with the right hand on the rear handle
1
.
Proper Hand Position (Fig.K)

WARNING: To reduce the risk of serious personal injury,
ALWAYS use proper hand position asshown.

WARNING: To reduce the risk of serious personal
injury, ALWAYS hold securely in anticipation of a
suddenreaction.
OPERATION

WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An
accidental start‑up can causeinjury.
Transporting Chain Saw (Fig.A, J)
• Always remove the battery from the tool and cover the
guide bar
11
with the scabbard
18
when transporting
thesaw.
Saw Chain and Guide Bar Oiling (Fig.A, I)
Auto Oiling System
This chain saw is equipped with an auto oiling system that
keeps the saw chain and guide bar constantly lubricated.
1. The oil level indicator
16
shows the level of the oil in the
chain saw. If the oil level is less than a quarter full, remove
the battery from the chain saw and refill the oil tank with
the correct type of oil.
2. Always empty oil tank when finishedcutting.
3. Always empty oil tank before storing this unit.
NOTE: Do not operate this chain saw without oil.
NOTE: Always use a high‑quality, biodegradable bar
and chain oil for proper saw chain and bar lubrication.
When pruning trees, vegetable‑based bar and chain oil is
recommended, as mineral‑based oils may harm living trees.
Never use dirty, used, or contaminated oil. Doing so may
damage the tool.
Filling the Oil Reservoir
1. Unscrew counterclockwise and then remove the oil
cap
17
. Fill the reservoir with the recommended bar and
chain oil until the oil level has reached the top of the oil
level indicator
16
.
2. Refit the oil cap and tightenclockwise.
3. Periodically switch the chain saw off and check the oil
level indicator to ensure the bar and chain are being
properlyoiled.
Adjusting the Guide Bar Oil Flow (Fig.A, I)
This DCCS674 is equipped with an adjustable oiling system.
The flow of saw chain and guide bar lubrication can be set
for different types of wood and cutting techniques. The saw
chain and guide bar lubrication feed rate is suitable for most
applications when the oil flow adjust screw
9
is in positioned
in between the maximum
29
and minimum
28
positions.
To reduce the flow:
1. Using the screwdriver end of the wrench
22
, twist
the oil flow adjust screw
9
clockwise towards the
minimum
28
position.
To increase the flow:
1. Using the screwdriver end of the wrench
22
, twist
the oil flow adjust screw
9
counter‑clockwise
maximum
29
position.
Replacement chains and bars are available from your
nearest authorized servicecenter.
The DCCS674 chainsaw is compatible with the following
DeWALT accessories when using the supplied .325 pitch,
7‑tooth sprocket
27
(NA265339):
SAW CHAINS GUIDE BARS
12" (30cm) DWO1DTX612 12" (30cm) DWZCSBX12
14" (35cm) DWO1DTX614 14" (35cm) DWZCSBX14
16" (40cm) DWO1DTX616 16" (40cm) DWZCSBX16
The DCCS674 chainsaw is also compatible with the following
DeWALT accessories when using the 3/8" pitch, 6‑tooth
sprocket (90585879):
SAW CHAINS GUIDE BARS
12” (30cm) DW01DT612 12” (30cm) DWZCSB12
16” (40cm) DW01DT616 16” (40cm) DWZCSB16
before performing the following operations. Failure to
do this could result in serious personalinjury.
1. To remove the saw chain
12
, place the saw on a flat,
firmsurface.
2. Remove sprocket cover
13
as described in Installing the
Guide Bar and Saw Chainsection.
3. Rotate the chain tension screw
15
using the flat
screwdriver end of thewrench
22
. Turning the screw
counterclockwise allows the guide bar
11
to recede
and reduces the tension on the chain so that it may
beremoved.
4. Wearing protective gloves, grasp the saw chain and lift
the worn saw chain out of the groove in the guidebar.
5. Flip guide bar over every time you replace the chain to
ensure evenwear.
6. Place the new chain in the slot of the guide bar, making
sure the saw teeth are facing the correct direction by
matching the arrow and graphic of the saw chain on the
sprocket cover
13
shown in Fig.H.
7. Follow instructions for Installing the Guide Bar and SawChain.
