14 15
User Manual
EN
Specifications
Laser Tool
Light Source Laser diodes
Laser Wavelength 620 – 690nm visible (RED) 510 – 530nm visible (GREEN)
Laser Power ≤1.50mW (each beam) CLASS 2 LASER PRODUCT
Working Range 20m (±65’) RED 35m (±115’) GREEN
50m with detector 60m with detector
Accuracy (plumb) ±1/8” per 30’ (±3mm per 9m)
Accuracy (Level): ± 1/8” per 30’ (±3mm per 9m)
Indicators
Battery Low 1 x LED Flashing on Battery meter
Unit Not Powered Off With Pendulum
Lock Switch
4 x LED Flashing on Battery meter
Flashing Laser Beams Tilt range exceeded/unit is not level
Power Source 4 AA (1.5V) size batteries (6V DC) or 12V Dewalt Battery Pack
Operating Temperature 14°F to 122°F (-10°C to 50°C)
Storage Temperature -5°F to 140°F (-20°C to 60°C)
Humidity Maximum relative humidity 80% for temperatures up to 88°F (31°C) decreasing
linearly to 50% relative humidity at 104°F (40°C)
Environmental Water & Dust Resistant to IP65
Notes
