right- handed users. If the belt hook is not desired at all, it can
be removed from thetool.
To move the belt hook
9
, remove the screw
10
that holds it in
place then reassemble on the opposite side. Be sure to securely
tighten thescrew.
Variable Speed Trigger Switch (Fig. A)
To turn the tool on, squeeze the trigger switch
1
. To turn
the tool off, release the trigger switch. Your tool is equipped
with a brake. The chuck will stop when the trigger switch is
fullyreleased.
The variable speed switch enables you to start the application at
a slow speed. The further you squeeze the trigger, the faster the
tool will operate. For maximum tool life, use variable speed only
for starting holes orfasteners.
NOTE: Continuous use in variable speed range is not
recommended. It may damage the switch and should
beavoided.
Forward/Reverse Control Button (Fig. A)
A forward/reverse control button
2
determines the direction of
the tool and also serves as a lock-offbutton.
To select forward rotation, release the trigger switch and
depress the forward/reverse control button on the right side of
thetool.
To select reverse, depress the forward/reverse control button on
the left side of the tool. The centre position of the control button
locks the tool in the off position. When changing the position of
the control button, be sure the trigger isreleased.
NOTE: The first time the tool is run after changing the direction
of rotation, you may hear a click on start up. This is normal and
does not indicate aproblem.
Worklight (Fig. A)
There is a worklight
7
located on the foot of the tool. The
worklight will be activated when the trigger switch isdepressed.
When the trigger is released, the worklight will stay illuminated
for up to 20 seconds. If the trigger switch remains depressed,
the worklights will remainon.
NOTE: The worklight is for lighting the immediate work surface
and are not intended to be used as aflashlight.
Mode Selector (Fig. A, C)
Your tool is equipped with a mode selector
8
which allows you
to select low, high, or Precision Wrench™ mode.
Select the mode based on the application and control the speed
of the tool using the variable speed trigger
1
.
Precision Wrench™ (Fig. C)
In addition to low speed impacting modes, this tool features
the Precision Wrench™ mode which grants the user greater
control in both fastening and loosening applications. When set
in forward, the tool will fasten at 2000 RPM until impact begins.
The tool will then pause for 0.5 seconds before continuing
to impact at a rate of 3100 IPM, providing the user with
greater control and reducing the chance of overtightening or
damagingmaterial.
When set in reverse, the tool will impact at a normal speed and
rate of 3100 IPM. Upon sensing that the fastener has broken
free, the tool will cease to impact and will reduce speed to help
prevent “run-off” of loose hardware.
DCF894/DCF894H
Low Mode Low Speed Impacting RPM 0–900
High Mode High Speed Impacting RPM 0–2000
Precision Wrench™ Mode Precision Wrench™ RPM 0–2000
Anvils (Fig. A, D, E)

WARNING: Use only impact accessories. Non-impact
accessories may break and cause a hazardous condition.
Inspect accessories prior to use to ensure that it con tains
nocracks.

CAUTION: Inspect anvils, detent pins and hog rings prior
to use. Missing or damaged items should be replaced
beforeuse.
Place the switch in the locked off (centre) position or remove
battery pack before changingaccessories.
Anvil with Detent Pin (Fig. D)
DCF894
To install an accessory on the anvil, align the hole in the
side of the accessory with the detent pin
13
on the anvil
3
.
Press the accessory on until the detent pin engages in the hole.
Depression of detent pin may be necessary to aid installation of
accessory.
To remove an accessory, depress the detent pin through the
hole and pull the accessory off.
Anvil with Hog Ring (Fig. E)
DCF894H
To install an accessory on the hog ring anvil, firmly push
accessory onto the anvil
3
. The hog ring
14
compresses to
allow the accessory to slide on. After accessory is installed, the
hog ring applies pressure to help provide accessoryretention.
To remove an accessory, grasp the accessory and firmly pull
itoff.
NOTE: The thru-hole (Fig.E) allows an O-ring with retaining pin
or a 1-piece retaining pin to be used to help secure sockets and
accessories to thetool.
OPERATION
Instructions for Use

WARNING: Always observe the safety instructions and
applicableregulations.

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
