Cut a piece of 38 mm x 89 mm timber
42
(about 61 cmlong)
to keep blades from turning when removing the blade
assemblybolt
43
.
WARNING: Use gloves and proper eye protection. Turn the
mower on its side. Be careful of sharp edges of blades.
1. Position the mower on its side, with two wheels flat on
theground.
2. Position the 38 mm x 89 mm timber
42
between the blade
assembly
47
and outer lip of deck as shown in Fig. X to
keep the blades from turning.
3. Unscrew and remove the blade assembly bolt
43
counterclockwise with a 14 mm (9/16") wrench
44
(not
included) as shownin Fig.X, Y.
4. Remove the keyed spacer
45
and blade assembly
47
from
the blade shaft
49
.
5. Secure the blade assembly
47
in a vise
34
as shown inFig. Z.
6. Unscrew the four blade nuts
51
counterclockwise
with a 14 mm (9/16") wrench
44
(not included) as
showninFig.Z. First unscrew the two blade nuts
51
for
blade 1
52
and remove blade 1. Then unscrew the two
blade nuts
51
for blade 2
53
and pull blade 2 from the
blade hub
48
.
NOTE: The mower blades
52
and
53
have keyed
mounting holes
55
permitting them to only be installed
onto the blade hub
48
in the correctorientation.
7. Examine all pieces for damage and replace ifnecessary.
8. Install sharpened or new blades onto the blade hub
48
as
shown in Fig.AA, BB.
9. Blade 2
53
is installed first, the bolt holes being aligned
with the outer blade studs
56
and keyed mounting
hole
55
on the blade hub
48
as shown in Fig. AA.
NOTE: Ensure the keyed mounting hole
55
engages the
key
57
on the blade hub
48
as shown in Fig.AA. The
key
57
should be proud of blade 2
53
.
10. Blade 1
52
is installed second, the bolt holes being aligned
with the inner blade studs
58
and keyed mounting hole
55
on the blade hub
48
as shown inFig.BB.
NOTE: Ensure the keyed mounting hole
55
engages
the key
57
on the blade hub
48
and sits flush as shown
inFig.BB.
NOTE: If blade 1
52
is not flush with the key
57
on the
blade hub
48
, then the blades have been mounted in the
incorrect order and must be reversed.
11. Thread the four blade nuts
51
onto the bladestuds
56
and
58
as shown in Fig. AA, BB. Hand tighten the four
blade nuts
51
.
NOTE: When replacing sharpened or new blades on blade
hub
48
make sure the bottom of the blade as marked
Grass Side will be facing the ground when the mower is
returned to its normal uprightposition.
12. Secure the blade assembly
47
in a vise
34
. Tighten the four
blade nuts
51
clockwise with a 14 mm (9/16") wrench
44
(not included). Torque the four blade nuts
51
to 18-27 Nm
(13-20ft-lbs).
Optional Accessories
WARNING: Since accessories, other than those offered
by
DeWALT, have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only DeWALT-recommended
accessories should be used with thisproduct.
Consult your dealer for further information on the
appropriateaccessories.
• Always release the bail handle to turn mower off, remove
safety key and battery pack when leaving it unattended
even for a short period oftime.
The following suggestions will help you to obtain
optimum runtime from your cordless mower:
• Slow down your cutting pace in areas where the grass is
especially long orthick.
• Avoid mowing when the grass is wet from rain or
dew-soaked.
• Cut your lawn frequently, especially during high
growthperiods.
NOTE: It is recommended that your battery pack be recharged
after each use to prolong the battery pack life. Frequent charging
will not harm your battery pack, and will ensure that the battery
pack is fully charged and ready for its next use.
NOTE: Storing the battery pack not fully charged will
shortenitslife.
MAINTENANCE
This product has been designed to operate over a long period of
time with a minimum of maintenance. Continuous satisfactory
operation depends upon proper care and regularcleaning.
DANGER: To reduce the risk of serious personal
injury, turn unit off and remove the safety key and
battery pack before making any adjustments or
removing/installing attachments or accessories. An
accidental start-up can causeinjury.
The charger and battery pack are notserviceable.
Removing and Installing Blades
(Fig. X–DD)
DANGER: RISK OF INJURY. WHEN REASSEMBLING THE
BLADE SYSTEM, ENSURE EACH PART IS REINSTALLED
CORRECTLY, AS DESCRIBED BELOW. IMPROPER ASSEMBLY
OF THE BLADES OR OTHER PARTS OF THE BLADE SYSTEM
MAY CAUSE SERIOUSINJURY.
DANGER: To reduce the risk of serious personal
injury, turn unit off, remove safety key and battery
packs before making any adjustments or removing/
installing attachments or accessories. An accidental
start-up can causeinjury.
Replacement blades are available from your
nearest authorized servicecenter.
This mower requires
replacementblades: DT20902.
