To Attach the Suction Hose (Fig.L)
Use the suction hose to pull water from a bucket or other
fresh watersource.
NOTICE: Do not use to suction soap, chemicals, dirty
or corrosive liquids, such as window cleaner, plant food,
fertilizers or bleach. Do not use with saltwater.
NOTE: Avoid cross threading when installing the hose. Cross
threading will causeleaks.
1. To connect the suction hose
27
to the
pressurewasherunit
8
,thread the suction hose
collar
30
onto the water intake
17
.
NOTE: The nozzles listed below might not be included with your
pressure washer but are available for purchase at an additionalcost.
Common Spray Nozzles Common Applications
15° Orange Nozzle For brick ormasonry.
25° Green Nozzle For vinylsiding.
40° White Nozzle For automotivewashing.
Black Turbo Nozzle For abrasivecleaning.
Attaching Nozzles (Fig.K)

DANGER: Risk of fluid injection. Do not direct
discharge stream toward persons, unprotected skin,
eyes or any pets or animals. Serious injury willoccur.

WARNING: Flying objects could cause risk of serious
injury. DO NOT attempt to change nozzles while
pressure washer is running. Turn pressure washer unit
OFF before changingnozzles.
1. To connect a nozzle to the spray wand
2
, pull the quick
connect collar
3
toward the spray wand and insert the
appropriatenozzle.
2. Release the quick connect collar to lock the nozzle inplace.
3. Give the nozzle a firm tug after the quick connect collar
has locked intoplace to ensure the nozzle is locked
intoplace.
Attaching Garden Hose (Fig.J)
NOTE: Before connecting the garden hose to the pressure
washer unit, run water through the garden hose for thirty
seconds to clear any debris from inside thegardenhose.
1. To connect a garden hose to the
pressurewasherunit
8
,place the end of the
gardenhose
38
inside the water intake
17
.
2. Securely tighten the garden hose byhand.
NOTE: Always disconnect the garden hose afterusage.
NOTE: Avoid cross threading when installing the hose. Cross
threading will causeleaks.
1. To connect the high pressure hose
1
to the handle
grip
5
, thread the hose collar
37
onto the inlet
coupler
31
.
2. To connect the high pressure hose to the pressure
washer unit
8
, thread the hose collar
36
onto the high
pressure water outlet
18
.
Attaching High Pressure Hose (Fig.I)

CAUTION: NEVER PULL WATER SUPPLY HOSE TO
MOVE pressure washer. This could damage hose and/
or pumpinlet.
NOTE: Uncoil the high pressure hose
1
before installation to
preventkinks.
High Pressure and Suction Hose Storage
(Fig.I)
This pressure washer has a built in storage area to carry the
high pressure hose. The coiled hose is secured between the
hose storage brace
31
and the pressurewasherunit
8
.
1. To access the high pressure hose
1
or the suction
hose
27
, unlock the hose storage latch
32
and
swing the hose storage brace
31
away from the
pressurewasherunit
8
.
2. Unwrap the hose storage strap
33
and remove the hose
from the pressurewasherunit
8
.
3. Swing the hose storage brace
31
closed and lock
the hose storage latch
32
securing the hose storage
brace
31
to the pressurewasherunit
8
.
Assembling Spray Wand (Fig.G)
1. To connect the spray handle
4
to the handle grip
5
,
insert the threaded end of the spray handle onto the
threaded end of the handle grip. Rotate the spray handle
4
clockwise until fullytightened.
2. To connect the spray wand
2
to the sprayhandle
4
,insert
the threaded end of the spray wand into the threaded
collar
40
of the spray handle. Rotate the threaded
collar
40
clockwise until fullytightened.
Accessory Storage Compartment (Fig.F)
This pressure washer has a built in accessory storage
compartment
34
to carry the spray wand, spray handle,
handle grip and turbonozzle.
1. To unlock the storage door
10
, rotate the door
latch
11
counterclockwise and flip the door open
to access the spray wand
2
, spray handle
4
, handle
grip
5
, and turbo nozzle
22
.
2. To lock the storage door
10
, place the storage door in the
closed position. Rotate the door latch
11
clockwise to lock
the storage door into position.
Telescoping Handle (Fig.A, E)
This pressure washer has a convenient, built in telescoping
handle and transportwheels.
1. To unlock the telescoping handle
12
, press the handle
release button
13
and slide the handle upwards. You will
hear an auidible click when it snaps intoposition.
2. To store the telescoping handle
12
, press the handle
release button
13
and slide the telescoping handle
down and into the pressure washer body. You will hear an
auidible click when it snaps intoposition.
3. To move the pressure washer
8
, tilt the unit so the
transport wheels
15
are touching the ground and pull the
unit by the telescopinghandle.
