DeWalt DCS438B-B3 User Manual

37
ENGLISH
Mounting, Removing and Adjusting the
Dust Shroud (Fig. F)
NOTE: The dust shroud is only for tile/concrete and drywall
cutting applications to connect to a vacuum for dust
collecting. We do not recommend use of the shroud for
metal cuttingapplications.
1. Remove thebattery.
2. With the wheel properly installed, rotate the guard
12
all the wayforward.
3. Loosen the depth of cut wing nut
11
and fully extend
the shoe. Hand‑tighten the depth of cutknob.
4. Maneuver the upper guard and wheel into the dust
shroud assembly
9
and rotate tool to lock in place.
The front of the guard will rest against the stop inside
the assembly, and the back of the guard will catch the
release tab
21
.
To Remove the Dust Shroud
1. Remove thebattery.
2. Loosen the depth of cut wing nut and fully extend the
shoe. Hand‑tighten the depth of cut wingnut.
Adjusting the Guard Angle (Fig. E)

WARNING: Remove battery first. To reduce the risk of
injury when grinding, ALWAYS adjust the guard to
provide the best control and protection. ALWAYS wear
gloves to protect your hands when adjusting theguard.
You can adjust the angle of theguard.
1. Remove thebattery.
2. Grasp the guard
12
firmly and rotate to desiredangle.
The guard can rotate 30degrees, forward orbackward.
5. Slip the inner flange over the spindle.
NOTE: When intsalling 7/16" wheels, place the 7/16"
adaptor
17
over the innerflange.
6. Slip wheel over spindle. Make sure wheel goes over pilot
diameter of innerflange.
NOTE: When installing diamond*** wheels, always
match direction of rotation of the wheel to the desired
direction of rotation of the tool. Diamond*** wheels
will not cut effectively unless the direction marked on
the wheel matches the direction of rotation. Check the
setting of the forward/reverse/lock off button
5
to make
sure it matches the direction marked on thewheel.
7. Slip on outer flange with the flat side towards the
cut‑offwheel.
NOTE: The text "LOOSE TIGHTEN" will be visible when
installedcorrectly.
8. Start threading on spindle screw which will self align
outer flange. Make sure the wheel is fitted in the
correctorientation.
9. Engage spindle lock button and tighten spindle screw
with wrench. Do not over tighten spindlescrew.
10. Turn wheel by hand to ensure it is properly centered. The
wheel should not hit the shoe, guard or spindle screw.
The spindle screw and flanges should betight.
Installing Wheels (Fig. A, D, J)

WARNING: Burn Hazard. Sharp parts. ALWAYS wear
gloves when changing wheels. Wheels have sharp
edges or may get extremely hot during operation, and
may damage barehands.

WARNING: To reduce the risk of injury, only use wheels
that are no greater than 3" (76mm) in diameter, have
an inner diameter of 3/8” (or 7/16” if using adapter
ring), and without cutting teeth. Thickness of wheel not
to exceed 0.09” (2.2mm). Never force a wheel onto the
machine or alter the size of the arborhole.

WARNING: Since accessories, other than those offered
by DeWALT, have not been tested with this product, use
of such accessories with this tool could be hazardous.
To reduce the risk of injury, only DeWALT recommended
accessories should be used with thisproduct.
1. Remove thebattery.
2. Lay unit on a firm surface, with the spindle
15
facingupward.
3. Hold spindle lock button
6
to keep the spindle
fromturning. Spindle threads are lefthand.
4. Using supplied 6mm wrench
13
, remove spindle
screw
19
, outer flange
18
, used wheel
20
if one
is installed and inner flange
16
. Spindle threads are
lefthand.
Wheels

WARNING: To minimize the risk of eye injury, always
use eye protection. Carbide is a hard but brittle
material. Foreign objects in the workpiece such as wire
or nails can cause tips to crack or break. Mount the
wheel securely in proper direction of rotation before
using, and always use a clean, sharpwheel.

WARNING: To reduce the risk of injury, only use wheels
that are no greater than 3" (76mm) in diameter, have
an inner diameter of 3/8” (or 7/16” if using adapter
ring), and without cutting teeth. Thickness of wheel not
to exceed 0.09” (2.2mm). Never force a wheel onto the
machine or alter the size of the arborhole.
A dull wheel will cause slow inefficient cutting, overload the
motor, could cause excessive splintering, and could increase
the possibility of kickback. Please refer to the table below to
determine the correct wheel for yourapplication.
Wheel type Application
Diamond*** Multi‑Material
Wheel (DW8530)
Drywall, fiber cement, plastic, steel, non
ferrous materials
Bonded Abrasive Wheel
(DW8711)
Steel, stainless steel, non‑ferrous materials
Diamond*** Tile Wheel
(DW47350)
Ceramic Tile, Porcelain and Granite/Marble/
Stone
ASSEMBLY AND ADJUSTMENTS

WARNING: To reduce the risk of serious personal
injury, turn unit off and remove the battery pack
before making any adjustments or removing/
installing attachments or accessories. An accidental
start‑up can causeinjury.
