ENGLISH
11
One-Touch
TM
Two-Touch
TM
Setting Guard Adjustment Options
To adjust the guard release lever
9
for desired
adjustmentoption:
1. Remove screw
12
using a T20 bit.
2. Remove the guard release lever taking note of the spring
position. Choose the end of the lever for the desired adjustment
option. One‑touch™ will use the slanted end of the guard
release lever
9
to engage the alignment holes
15
on the guard
collar. Two‑touch™ will use the squaredend to engage the
alignment holes
15
on the guard collar.
3. Replace the lever, positioning the chosen end under the
spring
13
. Ensure the lever is in proper contact with thespring.
4. Replace screw and torque to 2.0‑3.0 Nm. Ensure proper
installation with spring return function by depressing guard
release lever
9
.
Mounting Guard (Fig. D)
CAUTION: Prior to mounting guard, ensure the screw, lever,
and spring are fitted correctly before mounting theguard.
1. With the spindle facing the operator, press and hold the
guard release lever
9
.
2. Align the lugs
21
on the guard with the slots
14
on the
gearcase.
3. Push the guard down until the guard lugs engage and rotate
them in the groove on the gear case hub. Release the guard
release lever.
4. To position the guard:
One-touch
TM
: Rotate the guard clockwise into the desired
working position. Press and hold the guard release lever
9
to
rotate the guard in the anti‑clockwise direction.
Two-touch
TM
: Press and hold the guard release lever
9
.
Rotate the guard clockwise or anti‑clockwise into the desired
workingposition.
NOTE: The guard body should be positioned between
the spindle and the operator to provide maximum
operatorprotection.
The guard release lever should snap into one of the alignment
holes
15
on the guard collar. This ensures that the guard
issecure.
5. To remove the guard, follow steps 1–3 of these instructions
in reverse.
Flanges and Wheels
Mounting Non-Hubbed Wheels (Fig. E)
WARNING: Failure to properly seat the flange/ clamp
nut/ wheel could result in serious injury (or damage to the tool
orwheel).
CAUTION: Included flanges must be used with depressed
centre Type 27 and Type 42 grinding wheels and Type41 cutting
wheels. See the Accessory and Guard Applications Chart for
more information.
WARNING: A closed, two-sided cutting wheel guard is
re quired when using cutting wheels.
WARNING: Use of a damaged flange or guard or fail ure to
use proper flange and guard can re sult in injury due to wheel
breakage and wheel contact. See the Accessory and Guard
Applications Chart for more information.
1. Place the tool on a table, guard up.
2. Install the unthreaded backing flange
4
on spindle
2
with
the raised centre (pilot) facing the wheel.
3. Place wheel
16
against the backing flange, centring the
wheel on the raised centre (pilot) of the backing flange.
4. While depressing the spindle lock button and with the hex
depressions facing away from the wheel, thread the threaded
locking flange
5
on spindle so that the lugs engage the two
slots in the spindle.
5. While depressing the spindle lock button, tighten the
threaded locking flange
5
:
a. Tighten standard clamp nut using a wrench
20
.
b. Tighten a keyless clamp nut by hand. (Only use a keyless
clamp nut if it is in perfect condition.) Refer to Package
Contents.
6. To remove the wheel, depress the spindle lock button and
loosen the clamp nut.
Mounting Sanding Backing Pads (Fig.B, F)
NOTE: Use of a guard with sanding discs that use backing pads,
often called fiber resin discs, is not required. Since a guard is
not required for these accessories, the guard may or may not fit
correctly if used.
WARNING: Failure to properly seat the flange/ clamp
nut/ wheel could result in serious injury (or damage to the tool
orwheel).
WARNING: Proper guard must be reinstalled for grinding
wheel, cutting wheel, sanding flap disc, wire brush or wire wheel
applications after sanding applications are complete.
1. Place or appropriately thread backing pad
17
on thespindle.
2. Place the sanding disc
18
on the backing pad
17
.
3. While depressing spindle lock button
1
, thread clamp
nut
19
on spindle, piloting the raised hub on the clamp nut
into the centre of san ding disc and backingpad.
4. Tighten the clamp nut by hand. Then depress the spindle
lock button while turning the sanding disc until the sanding disc
and clamp nut are snug.
5. To remove the wheel, grasp and turn the backing pad and
sanding pad while depressing the spindle lock button.
Mounting and Removing Hubbed Wheels
(Fig.B,E)
Hubbed wheels install directly on the M14 threaded spindle.
Thread of accessory must match thread of spindle.
1. Remove backing flange by pulling away from tool.
2. Thread the wheel on the spindle
2
by hand.
3. Depress the spindle lock button
1
and use a wrench to
tighten the hub of the wheel.
4. Reverse the above procedure to remove the wheel.
NOTICE: Failure to properly seat the wheel before turning the tool
on may result in damage to the tool or the wheel.
Mounting Wire Cup Brushes and WireWheels
(Fig.B,E)
WARNING: Failure to properly seat the flange/ clamp
nut/ wheel could result in serious injury (or damage to the tool
orwheel).
