DATE CODE POSITION
The date code, which also includes the year of
manufacture, is printed into the housing.
Example:
2014 XX XX
Year of Manufacture
Package Contents
The package contains:
1 Motor unit
1 Collet 6 mm(1/4")
1 Wrench # 17 mm
1 Straight edge guide
1 Roller bearing guider
1 Dust Extraction Adaptor
1 Instruction manual
 • Checkfordamagetothetool,partsor
accessories which may have occurred
during transport.
 • Takethetimetothoroughlyreadand
understand this manual prior to operation.
Description (fig. 1, 3)
WARNING: Never modify the power
tool or any part of it. Damage or
personal injury could result.
a. On/off switch
b. Motor unit
c. Depth adjustment ring
d. Micro adjustment scale
e. Groove pins
f. Spindle lock button
g. Spindle
h. Collet
i. Collet nut
j. Cutter bit (not included)
k. Base
l. Sub-base
m. Sub-base screws
n. Quick release tabs
o. Locking lever
p. Locking lever adjustment screw
q. Guide slot
r. Straight edge guide
s. Roller bearing guide
t. Guide screw
hand or against the body leaves it unstable and
may lead to loss of control.
 • Neverrunthemotorunitwhenitisnot
inserted in one of the router bases. The
motor is not designed to be handheld.
 • Alwaysusestraight-cutters,rabbet-cutters,
profile cutters, slotter cutters or grooved knives
with a shank diameter of 6 mm(1/4") which
corresponds to the size of the collet in your tool.
 • Alwaysusecutterssuitableforaspeedof
30,000 min
-1
and marked accordingly.
WARNING: Never use cutters with
a diameter exceeding the maximum
diameter indicated in the technical data.
 • Forstraight-cutters,rabbet-cutters,profile
cutters, the maxium shank diameter MUST
be 8 mm, the maximum diameter MUST be
36mm., the maximum cutting depth MUST be
10 mm.
 • Forslottercutters,themaximumshank
diameter MUST be 6 mm(1/4") and the
maximum diameter MUST be 25.4 mm.
 • Forgroovedknives,themaximumshank
diameter MUST be 6 mm(1/4"), the maximum
diameter MUST be 25.4 mm and the maximum
cutting width MUST be 4 mm.
Residual Risks
In spite of the application of the relevant safety
regulations and the implementation of safety
devices, certain residual risks cannot be avoided.
These are:
– Impairment of hearing.
– Risk of personal injury due to flying particles.
– Risk of burns due to accessories becoming hot
during operation.
– Risk of personal injury due to prolonged use.
Markings on Tool
The following pictograms are shown on the tool:
Read instruction manual before use.
Wear ear protection.
Wear eye protection.
