User Manual
Contents
• Safety
• Product Overview
• Batteries and Power
• Operation
• Accuracy Check and Calibration
• Specications
User Safety
WARNING:
Read and understand all instructions. Failure
to follow all instructions listed below may result in
electric shock, re and/or serious personal injury.
WARNING:
Laser Radiation Exposure. Do not disassemble
or modify the laser level. There are no user
serviceable parts inside. Serious eye injury
could result.
WARNING:
Hazardous Radiation. Use of controls or
adjustments or performance of procedures other than
those specied herein may result in hazardous
radiation exposure.
CAUTION:
LASER RADIATION - DO NOT STARE INTO THE
LASER BEAM. Class 2 Laser Product.
• The label on your tool may include the following symbols.
V volts
mW milliwatts
Ah Ampere Hours
laser warning symbol
nm wavelength in nanometers
2 Class 2 Laser
Do not stare into the laser beam.
• Do not remove or deface warning labels. Removing
labels increases the risk of exposure to radiation.
• Position the laser securely on a level surface. Damage
to the laser or serious injury could result if the laser falls
Laser Information
• The DCE088R and DCE088G Laser Levels are Class 2
laser products.
• The DCE088R and DCE088G lasers are self-leveling
laser tools that can be used inside and outside for
horizontal (level), vertical and plumb alignment projects.
WARNING:
Read and understand all instructions. Failure to
follow all instructions listed below may result in
electric shock, re and/or serious personal injury.
Work Area
• Keep your work area clean and well lit. Cluttered benches
and dark areas invite accidents.
• Do not operate laser tools in explosive atmospheres, such
as in the presence of ammable liquids, gases, or dust.
• Keep bystanders, children, and visitors away while operating
a laser tool. Distractions can cause you to lose control
Electrical Safety
• Usebatteryoperatedtoolonlywiththespecically
designed batteries. Use of any other batteries may create
a risk of re.
Product Overview
WARNING:
Never modify the tool or any part of it. Damage to the
laser or personal injury could result.
Figure 3 - Battery Interface
A
Figure 2 - Pendulum Lock
B
Figure 2 - Keypad
C
Figure 5B - ON/OFF button: horizontal laser line
D
Figure 5B - ON/OFF button: vertical laser line
E
Figure 5B - Battery Meter
F
Figure 3 - Magnetic pivot bracket
G
Figure 3 - Keyhole slot
H
Figure 5A - Tripod thread tting (1/4 - 20” & 5/8-11)
I
Warning Labels
For your convenience and safety, the following labels are on
your laser.
WARNING: To reduce the risk of injury, user
must read instruction manual.
WARNING: LASER RADIATION. DO NOT
STARE INTO BEAM. Class 2 Laser Product
• Do not operate the laser in explosive atmospheres,
suchasinthepresenceofammableliquids,gases,or
dust. Power tools create sparks which may ignite the dust
or fumes.
• Usethelaseronlywiththespecicallydesignated
batteries. Use of any other batteries may create a risk
of re.
• Store idle laser out of reach of children and other
untrained persons. Lasers are dangerous in the hands of
untrained users.
• Use only accessories that are recommended by the
manufacturer for your model. Accessories that may be
suitable for one laser, may create a risk of injury when used
on another laser.
• Toolservicemustbeperformedonlybyqualied
repair personnel. Service or maintenance performed by
unqualied personnel may result in injury. To locate your
nearest DeWALT service center go to
http://www.dewalt.com on the Internet.
• Do not use optical tools such as a telescope or transit
to view the laser beam. Serious eye injury could result.
• Do not place the laser in a position which may cause
anyone to intentionally or unintentionally stare into the
laser beam. Serious eye injury could result.
• Turn the laser off when it is not in use. Leaving the laser
on increases the risk of staring into the laser beam.
• Do not disassemble the laser tool. There are no user
serviceable parts inside.
• Do not modify the laser in any way. Modifying the tool
may result in Hazardous Laser Radiation Exposure.
• Do not operate the laser around children or allow
children to operate the laser. Serious eye injury may
result.
Figure 5A - Ceiling Mount
J
Figure 5A - Clamp
K
Figure 5A - Screw Hole
M
Batteries and Power
• This tool is powered by the following DeWALT 10.8V Battery
packs: DCB120, DCB127 or may also be powered using the
DEWALT AA Starter pack which can carry 4 x AA batteries.
Note: The AA starter pack is recommended only for use with
the red laser
Battery Installation / Removal
(See gure
3
)
Using the AA Starter Pack:
CAUTION:
The AA starter pack is designed specically for
use only with the DeWALT 10.8V compatible laser
products and cannot be used with any other tools Do
not attempt to modify the product.
To install batteries:
• Lift up the battery compartment cover as shown in Figure
4
.
• Insert four fresh AA batteries in the compartment, placing
the batteries according to (+) and (–) on the inside of the
compartment.
• Install the AA starter Battery pack as shown in Figure
3
.
Using the 10.8V DEWALT Rechargeable
Pack:
• Install the 10.8V Battery pack as shown in
Figure
3
.
WARNING:
Batteries can explode, or leak, and can cause
injuryorre. To reduce this risk carefully follow all
• Carefully follow all instructions and warnings on the battery
instructions on the label and package and accompanying
Battery Safety Leaet.
• Always insert batteries correctly with regard to polarity
(+ and –), marked on the battery and the equipment.
• Do not short battery terminals.
• Do not charge disposable batteries.
• Do not mix old and new batteries. Replace all of them at the
same time with new batteries of the same brand and type.
User Manual
