13
ENGLISH
Indicators
Stage 1Charging
Stage 2Charging
Fully Charged
Hot/Cold Pack Delay*
* The red light will continue to blink, but a yellow indicator light will be illuminated during
this operation. Once the battery pack has reached an appropriate temperature, the yellow
light will turn off and the charger will resume the chargingprocedure.
The compatible charger(s) will not charge a faulty battery pack. The charger will indicate
faulty battery by refusing tolight.
NOTE: This could also mean a problem with acharger.
If the charger indicates a problem, take the charger and battery pack to be tested at an
authorised servicecentre.
Hot/Cold Pack Delay
When the charger detects a battery pack that is too hot or too cold, it automatically
starts a Hot/Cold Pack Delay, suspending charging until the battery pack has reached an
appropriate temperature. The charger then automatically switches to the pack charging
mode. This feature ensures maximum battery packlife.
A cold battery pack will charge at a slower rate than a warm batterypack.
The DCB118 charger is equipped with an internal fan designed to cool the battery pack. The
fan will turn on automatically when the battery pack needs to becooled.
Never operate the charger if the fan does not operate properly or if ventilation slots are
blocked. Do not permit foreign objects to enter the interior of thecharger.
Electronic Protection System
XR Li‑Ion tools are designed with an Electronic Protection System that will protect the
battery pack against overloading, overheating or deepdischarge.
The tool will automatically turn off if the Electronic Protection System engages. If this
occurs, place the lithium‑ion battery pack on the charger until it is fullycharged.
