DeWalt XR Li-ion DWH161 User Manual

11
ENGLISH
Cleaning

WARNING: Do not use a spray system, pressure jet washer
or running water forcleaning.

WARNING: Wear approved eye protection and approved
dust mask when performing thisprocedure.

WARNING: Do not use a brush or compressed air to clean
the dust collector orfilter.

WARNING: Never use solvents or other harsh chemicals
for cleaning the non-metallic parts of the dust extractor.
These chemicals may weaken the materials used in these
parts. Use a cloth dampened only with water and mild
soap. Never let any liquid get inside the dust extractor;
never immerse any part of the dust extractor into aliquid.
During intensive use the dust collector becomes clogged
with dust. Refer to Replacing The Dust Collector Box Filter
Assembly, underMaintenance.
For cleaning and maintenance in a way that avoids exposing
maintenance personnel and other persons to any hazards, wear
personal protective equipment. Clean the maintenance area in a
way that prevents hazardous substances from escaping into the
surroundingenvironment.
Lubrication
Your dust extractor requires no additionallubrication.
Replacing the Dust Collection Box Filter
Assembly (Fig.F)

WARNING: Wear approved eye protection and approved
dust mask when performing thisprocedure.

WARNING: Replace any damaged filtersimmediately.
NOTE: The filter should be replaced after every 350 cycles
ofuse.
1. Press the dust collection box release buttons
2
and pull the
dust collection box away from the dust extraction system.
Once the catch mechanism is clear of the dust extraction
system the upper joint will also release allowing the dust
collection box to be removedcompletely.
2. Discard dust collection box
1
replace with a new filterbox.
3. Reattach the dust collection box to the dust extraction
system. First insert the rounded profile of the upper joint
into the recess on the dust extraction system. Pivot the dust
collection box down so that the release buttons click back
intoplace.
Wireless Tool Control Troubleshooting
LED Light
Pattern
Pairing Button System Status
Slow flash Not pressed Wireless Tool Control not paired
Fast flash Pressed Pairing Mode, Waiting for
signal from tool
Solid Not pressed Wireless Tool Control paired,
Waiting for command from tool
Filter Cleaning Mechanism
Suction power is dependent on the condition of the filter.
Therefore, the filter should be cleanedregularly.
The filter cleaning mechanism is a feature that uses the motor
in the dust extractor to force air through the filter. Refer
to Emptying the Dust Collection Box for instructions on
properuse.
Emptying the Dust Collection Box (Fig.F, G)

WARNING: The vacuum cleaner contains dust particles
that pose a risk to health. Emptying and maintenance
procedures, including the disposal of dust collectors,
should only be carried out by professionals. Suitable
protective equipment is required. Do not operate the
vacuum cleaner without the complete filter system.
Otherwise you endanger yourhealth.

WARNING: Wear approved eye protection and approved
dust mask when performing thisprocedure.

CAUTION: Do not clean with water or compressedair.
The dust collection box
3
should be emptied as soon as the
performance has noticeably decreased or isfull.
1. Press the dust collection box release buttons
4
and pull the
dust collection box away from the dust extraction system.
Once the catch mechanism is clear of the dust extraction
system the upper joint will also release allowing the dust
collection box to be removedcompletely.
2. To empty the dust collection box
3
position it over a
suitable container to catch the dust contained within it.
Lift up the assembly release latch
16
to open the dust
collection box, separating the canister from the lid. Gently
tapping the dust collection box will encourage any dust
trapped within the filter to also be removed. Once the filter
lid and canister are empty reattach them, ensuring the
assembly release latch
16
is securely fastened. Refer to
FigureG.
3. To reattach the dust collection box to the dust extraction
system first insert the rounded profile of the upper joint
into the recess on the dust extraction system. Pivot the dust
collection box down so that the release buttons click back
into place. Refer to FigureF.
4. With the dust collection box properly installed, depress the
filter cleaning mechanism
5
and turn on the dust extractor.
Allow the system to run for 5 seconds and release trigger.
This should be done after every emptying of the dust
collectionbox.
MAINTENANCE

WARNING: To reduce the risk of serious personal
injury, turn the dust extractor off and disconnect
battery pack before making any adjustments or
removing/installing attachments or accessories. An
accidental start-up can causeinjury.
The charger and battery pack are notserviceable.
