5, 7 & 9 GALLON SYSTEM
DESCRIPTION
QTYPART #
ADAPTER, 16MB-16BH 45°
1120188
ADAPTER, 20MB-16FOR
1120511
HOSE CLAMP, #201720107
12 & 17 GALLON SYSTEM
DESCRIPTIONQTY
PART #
ADAPTER, 20MB-20BH 45°
1120189
HOSE CLAMP, #24
1511002
Parts List
DESCRIPTIONQTY
PART #
BOLT, 5/16-18 X 0.75, WIZ FLANGE
4110444
NUT, 5/16", J-TYPE, CAGE, .5C
4110616
ADAPTER, 4BH-4MP
1120237
DIP STICK
1
220566
RESERVOIR WELDMENT1220570
VENT HOSE
1220587
FITTING, PLUG 1/2" PIPE1500175
FUEL FILTER
1
540031
HYDRAULIC ASSEMBLY
RESERVOIR
11/25/2009
220566
540031
220587
120237
220570
110444
110616
500175
RUNNING CHANGE
The above fittings were phased into usage
at the beginning of the 2010 model year.
See previous page for old fittings.
