Stop Adjustments (Continued)
Figure 5— Open and Closed Position Stop Identification
Valve
Size
Actuator
Size
Actuator Input Torque (ft-lbs)
Direct
Pressure
Drop(psi)
Reverse Pressure Drop (psi)
25
50
75
100
125
150
175
3 & 4
G6
4
4
4
5
5
5
5
5
5
G6
8
8
9
10
11
11
11
11
6
G6
8
8
9
10
11
11
11
11
8
G6
15
15
17
19
20
21
21
21
10
G6
22
22
25
29
33
36
N/A
N/A
10
G12
11
11
18
18
18
18
18
18
12
G6
29
29
29
29
N/A
N/A
N/A
N/A
12
G12
15
15
15
15
15
15
15
15
14
G12
18
18
24
29
34
34
34
N/A
16
G12
22
22
29
37
45
45
45
N/A
18
G12
26
26
35
45
55
55
N/A
N/A
20
G12
29
29
44
55
55
N/A
N/A
N/A
Note: The “N/A” designation in Table A indicates that the Valve/Actuator combination cannot be used for that
particular reverse pressure.
