Explosionszeichnung | assembly exploded diagram | Dessin éclaté

Disegno esploso | Dibujo de explosión

22.0MM

23.30MM

19.8MM

15.8MM

7401

7400

Steering gear tie rod assembly

Front upper tie rod assembly

Rear tie rod assembly

Steering tie rod assembly

7413

7415

7414

7415
