DF-models Z06-Evolution Instructions

Explosionszeichnung | assembly exploded diagram | Dessin éclaté
Disegno esploso | Dibujo de explosión
22.0MM
23.30MM
19.8MM
15.8MM
7401
7400
Steering gear tie rod assembly
Front upper tie rod assembly
Rear tie rod assembly
Steering tie rod assembly
7413
7415
7414
7415

DF-models Z06-Evolution Specifications

General

Scale	1:14
Drive type	4-wheel drive (4WD)
Motor type	Brushed
Engine type	Electric engine
Product type	Buggy
Housing color	Multi
Maximum speed	60 km/h
Built-in servo	Yes
Frequency band	2.4 GHz
Chassis material	Aluminum
Housing material	-
Suggested gender	Boy
Construction type	Ready-to-Run (RTR)
Recommended age (min)	- yr(s)
Battery voltage	7.4 V
Battery capacity	1500 mAh
Quantity	1
Cables included	USB

Weight and Dimensions

Width	205 mm
Height	120 mm
Length	310 mm
Weight	1000 g
Wheelbase	186 mm
Tire diameter	31 mm
Tire width (rear)	27 mm
Tire width (front)	73 mm
