Different Button Operation – option
⚫ Relay 1 can be programmed to momentary, latching or delay operation.
When learning a remote into the receiver, press button 2 to learn for latching or 3 for 10s delay operation.
⚫ Button 4 can be used to Arm in Stay mode.
When learning a remote into the receiver, press button 4 to learn for that option.
Learn a Remote
The receiver can enroll up to 25 remotes. Two remotes have been pre-learned into the receiver as part of
kit.
1. Press and hold the program button PROG on the receiver for one second; LED on.
2. Press any button on the remote to learn (You must learn the remote in by pressing button 1 to keep
default setting). LED flashes 3 times and stays on for 10s then off. Done. Note: if the LED only flashes
once, it means the remote has already been learned.
Delete all Remotes
Press and hold program button PROG on the receiver for 5 seconds till LED turns off. The LED flashes 10
times. Done.
Delete a single Stolen Remote
1. Find and bring back the remote which had been learned right before the stolen remote.
2. Press and hold program button PROG on the receiver for 1 second; LED on.
3. Press Button 1 and Button 2 simultaneously; LED flashes 5 times then off; successfully deleting the
stolen remote.
Arm/Disarm Notification - chirp/flash
The Outputs Chirp and Flash (switch to ground) on the receiver are used for Arm and Disarm notification.
Please refer to Reliance or DSC panel manual in relation to how to set up Arm and Disarm notification.
Specifications
Remote
⚫ Operating Range: A minimum of 50m (open air)
⚫ 433.92 MHz Keeloq rolling code: 4.3 billion combination; SAW resonator (filter) locked (+/- 75KHz)
⚫ Transmitting power: <10mW
⚫ Operating Voltage: 6 V powered by 2 x 3 VDC lithium batteries
⚫ Battery Life: 3 years under normal operating conditions
⚫ Current: <1uA standby; 12mA max.
⚫ Low battery indication: LED on the remote flashes when the button is pressed
⚫ Auto shutoff: the remote stops transmitting if a button gets pressed for 25s.
Receiver
⚫ Operating voltage: 9-15VDC; Current: 10mA Standby; 100mA max.
⚫ Outputs:
◼ Data – Arm (away/stay), Disarm and Panic. 4-wire harness provided
◼ Two programmable relay outputs; SPDT; rating 1A 24VDC/120VAC
◼ Chirp & Flash “Switch to Ground” outputs for Arm and Disarm notification
⚫ Standard capacity: 25 remotes
⚫ Mounting plate provided for quick receiver installation
