Brushed Truck Model Specifications
Length: 455mm(17.9”) (incl. F/R bumpers)
Width: 366mm(14.4”)
Height: 225mm(8.8”) (incl. body shell)
Wheelbase: 290mm(11.4”)
Front track/rear track: 293mm/298mm(11.5”/11.7”)
Tire size: Ф122*68mm(Ф4.8”/2.7”)
Wheel size: Ф72*48mm(Ф2.8”/1.9”)
Ground clearance: 74mm(2.9”)
Gear ratio: 10.97:1
Steering servo: 6kg
Brushless Truck Model Specifications
Length: 455mm(17.9”) (incl. F/R bumpers)
Width: 366mm(14.4”)
Height: 225mm(8.8”) (incl. body shell)
Wheelbase: 290mm(11.4”)
Front track/rear track: 293mm/298mm(11.5”/11.7”)
Tire size: Ф122*68mm(Ф4.8”/2.7”)
Wheel size: Ф72*48mm(Ф2.8”/1.9”)
Ground clearance: 76mm(3.0”)
Gear ratio: 15.19:1
Steering servo: 6kg
Radio System
A 2-channel radio system is required for the model. This includes 2.4GHz transmitter and receiver.
Please refer to 2.4GHz Transmitter Manual.
Battery and ESC information for brushed truck
The brushed truck comes with a 7-cell 8.4V SC type NiMh battery. The battery is with T-connector, so
does the battery charger. Besides, the ESC also has a T-connector to match it on the battery.
Below you may find the features and specifications of the high voltage ESC.
High Voltage ESC (Part# H126)
Features
1. Auto search throttle neutral point.
2. HF drive system
3. Over-heat protection (90C°)
4. Lipo battery low-voltage protection (2S Lipo-6.6V cutoff, 3S Lipo-9.9V shut down)
5. Low internal resistance & big capacity PCB board, providing great resistance to high current.
6. Forward, brake and reverse functions, good for both vehicles and boats.
Specifications
Forward current: 380A
Reverse current: 190A
Brake current: 250A
Voltage range: 4.8V-12.6V
PWM frequency: 1.5KHz
BEC voltage: 5V/2A
Operation
To obtain forward, brake and reverse functions and to switch battery types, kindly refer to the
2
