6 DTC Lookup
DTC Lookup menus allows to request DTC denitions stored in the code reader.
To Lookup DTCs:
1. Use the LEFT / RIGHT key to highlight DTC Lookup from Home Screen and press the ENTER
key.
2. Use the LEFT / RIGHT key to select the desired character, then press the UP / DOWN key to
change the digit you want to enter a valid code number. Press the ENTER key to conrm.
3. A screen with code number and its denition displays. If denition could not be found (SAE or
Manufacturer Specic), the code reader displays:“DTC denition not found! Please refer to
vehicle seice manual!” If a P1xxx, C1xxx, B1xxx or U1xxx code is entered, select a vehicle make
to look for DTC denitions. Press the BACK key to exit.
7 Reivew Data
The Playback option leads to screens for review of recorded test results.
To review recorded data:
1. Use the LEFT / RIGHT key to highlight Review Data from home screen and press the ENTER
key.
2. A screen with a list of test records displays. If no data is recorded, the message “No Data
available!” is displayed.
3. Use the UP / DOWN key to highlight an optional record and press the ENTER key. Details of the
tset record displays. View and analysis the recorded information then press BACK to exit.
OBDII / EOBD+CAN VD30 Code Reader User Manual
14
8 Print Data
The Print Data function is used to print test results through computer.
To print test results:
1. Connect the tool to computer with the supplied USB cable to power it on.
2. Use the LEFT / RIGHT key to select Print Data from home screen of the tool and press the
ENTER key to conrm. Use the UP / DOWN key to select desired data to print. If all recorded
data to be printed, use the UP / DOWN key to select Print All Data.
3. Press the ENTER key to conrm and printing.
Print Data 1/4
I/M Readiness
Vehicle Infromation
Modules Present
Print All Data
