GS

SCHEDA MONOFASE

PT

MC STARTSTOP

L

3

1

2

4

START

STOP

MICRO

1-4 = LINEA

2-3 = MOTORE

PONTE

FUSE

FUSIBILE 500mA

M

~

Av

Av

C

C

CONDENSATORE

m

F16 V400 (mod.12)

m

F20 V400 (mod.22)
