SYSTEM CONFIGURATIONS
MICRO5V2 - 5 CHANNEL SYSTEM
MICRO5V2 SIGNAL ENDPLATE
FRONT INPUT
SIGNAL HARNESS
REAR INPUT
SIGNAL HARNESS
MICRO5V2 POWER/SPEAKER ENDPLATE
FRONT AND REAR
CO-AXIALS/COMPONENTS
(4 Ohms OR 2 Ohms)
SUBWOOFER(s)
(4 Ohms OR 2 Ohms)
HEAD UNIT
(PREFERABLY WITH 5V OUTPUT)
