X-over output 1 output 2 output 3 output 4 output 5 output 6
2x2 Way+2S Low High Low High Msub Aux
2x3 Way Low Mid High Low Mid High
4 Way+2 Low Lo Mid Hi Mid High Aux Aux
5 Way+1 Sub Low Lo Mid Hi Mid High Aux
6Way Lo Sub Sub Low Lo Mid Hi Mid High
APPENDIX FOR DS216
Default X-over setting and names for all formats
122Hz-1k8Hz 1k8Hz-20kHz 122Hz-1k8Hz 1k8Hz-20kHz 25Hz-122Hz 20Hz-20kHz
25Hz-122Hz 122Hz-1k8Hz 1k8Hz-20kHz 25Hz-122Hz 122Hz-1k8Hz 1k8Hz-20kHz
20Hz-146Hz 146Hz-1k32Hz 1k32Hz-8kHz 8kHz-20kHz 20Hz-20kHz 20Hz-20kHz
20Hz-80Hz 80Hz-176Hz 176Hz-1k32Hz 1k32Hz-8kHz 8kHz-20kHz 20Hz-20kHz
20Hz-80Hz 80Hz-146Hz 146Hz-1kHz 1kHz-40kHz 4kHz-10k1Hz 10k1Hz-20kHz
Note:All filters set to 24dB Butterworth.
