Connection Diagram / Application Example
1
Headphones
6
Router
2
USB Stick
7
HDMI® Display
3
HDD / SSD (External Storage)
8
VGA Display
4
Mouse
9
Notebook / PC
5
SD / Micro SD Memory Cards
10
Power Supply
Note: 1. For video output, USB-C™ source devices must support
video output
2. Suggest charge for power supply to keep it work stable.
