The Real Panel
The rear panel view of the PoE switch consists of a DC power connector.
RJ-45 Ports ( Auto MDI/MDIX )
5 auto-sensing ports of 10Base-T, 100Base-TX or 1000Base-TX connections.
Port 1 to 4 can support Power over Ethernet to power devices.
Remark: MDI means connecting to another Hub or Switch while MDIX means con-
necting to a workstation or PC. Therefore, Auto MDI/MDIX means that you can con-
nect to another Switch or workstation without changing pin-to-pin or crossover ca-
bling.
DC Power Connector
Plug the female connector into the switch and male connector into a power outlet.
Support input voltages 44~57 VDC.
Product Specifications:
Item Description
Summarize
Fixed port 5x 10/100/1000Base-TX ports.
LED Indicators PWR, PoE, Link/Act LED.
Input voltage
100V～240V AC，50/60Hz (for power adapter)
48VDC (for switch)
Network Media 10BASE-TX: UTP category 5, 5e cable
100BASE-TX: UTP category 5, 5e cable
1000BASE-TX: UTP category 5, 5e cable
Forwarding Rate 10BASE-T: 14880pps / port
100BASE-TX: 148800pps / port
1000BASE-TX: 1488000pps / port
Power Supplies 65W
Operating tempera-
ture
0℃～40℃.
Storage temperature
-10℃～70℃.
Relative humidity
20%～85% (non-condensing).
