Digitus DS-55901 User Manual

１
1.1 FEATURES
This kind of the HDMI Repeater has many features that enable it to perform in a
superior manner. Among those features you will find:
 Support HDMI HighSpeed (1.3b)
 Support highest video resolution 1080p
 Support 225MHz/2.25Gbps per channel (6.75Gbps all channel) bandwidth
 An external power supply is not necessary, as long as signal source as well
as output device have their own power supply
 Support 12bit per channel (36bit all channel) deep color
 HDCP pass-through
 Iron Shell for better EMI elimination
 Support uncompressed audio such as LPCM
 Support compressed audio such as DTS Digital, Dolby Digital（including
DTS-HD and Dolby True HD
 8 levels of equalization settable by turning EQ from 0 to 7, so that support
different length of HDMI cable between 1m to 35m
 Unique designed structure for better connection
 Support 3D all format, including 1080p@23.98/24Hz,
720p@59.94/60Hz/50Hz.
2.0 SPECIFICATIONS
Signal Inputs/Output
Input Video Signal
5 Volts p-p (TTL)
Maximum Single Link Range
1920x1080P
Output Video
HDMI HighSpeed (1.3b)
HDMI Input/Output Connector
Type A 19 pin
Operating Frequency
Vertical Frequency Range
50/60Hz
Video Amplifier Bandwidth
2.25Gbps/225MHz
Resolutions(HDTV)
Interlaced(50&60Hz)
480i,576i,1080i
Progressive(50&60Hz)
480p,576p,720p,1080p
Mechanical
Size(H-W-D)
5X4X3.5MM
Weight(Net)
78g
Environmental
Operating Temperature
0
℃
to +70
℃
Operating Humidity
10% to 85 % RH (no condensation)
Storage Temperature
-10
℃
to +80
℃
Storage Humidity
5% to 90 % RH (no condensation)
Power Requirement

Digitus DS-55901 Specifications

General

Type	AV repeater
Product color	Black
Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p, 720p
Maximum transfer distance	35 m
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
HDMI in	1
DC-in jack	Yes
VGA (D-Sub) input ports	0
Operating voltage	5 V
UK Trade Tariff code	85437090
Harmonized System (HS) code	84733080
Country of origin	China

Weight and Dimensions

Package depth	50 mm
Package width	90 mm
Package volume	382.5 cm³
Package weight	150 g
