Dillon AFG Series User Manual

11
7. When the option you
want is displayed,
press the MORE
key. . . The choice is entered
into memory and the
unit displays the current
alarm band setting.
8. To change the choice
between outbd (out
of band) and inbd (in
band), press the UP
or DOWN arrow
keys until your
choice is displayed
and press the MORE
key. . . Your choice is entered
into memory and the
current value of the
audio option is dis-
played.
If you choose outbd, any displayed force falling
outside the lower and upper band points will
activate the alarm as you have configured it. If the
LED output is selected the red LED will illuminate
if the displayed force falls outside the band. When
the displayed force falls inside the band the green
LED will illuminate.
If you choose inbd, any displayed force now falling
inside the selected lower and upper band points
will activate the alarm as configured. If the LED
output has been selected in the previous mode,
then the red LED will illuminate if the displayed
force falls inside the band. When the displayed
force falls outside the band the green LED will
illuminate.
Alarm Band
