MENU ACCESS:
SAVING THE PARAMETERS:
Press the key during the start-
up procedure.
Press the key several times, until the display shows
SAVE?. Press the key to confirm.
Complete menu
on pages 24 - 25
Reactivation of printing
Printing always active.
Reactivation of printing after the weight has changed from zero.
Reactivation of printing after the weight has changed from instability.
Transmission mode.
Baud rate.
Parity.
Data bits.
Stop bits.
Transmission mode
Transmission on demand.
Standard string transmission when the key is pressed.
Transmission with Modbus protocol (refer to the Modbus protocol manual).
Transmission of the weight on DINI ARGEO 6-digit repeater.
Transmission with 485 protocol (enter the 485 address of the transmitter).
Extended string transmission when the key is pressed.
Continuous transmission of the extended string.
Continuous high speed weight transmission for conversion applications (single channel only)
Stable transmission of the extended string.
Continuous transmission of the standard string.
Stable transmission of the standard string.
Configuration of the PC port (COM.PC)
